NGINX Tutorial: Developing Modules
Table of contents.
- 1 Introduction
- 2.1 Getting started with the NGINX tutorial
- 2.2 Bootstrapping a local development environment
- 2.3 Ensure the local environment is working properly
- 3.1 Creating the build system
- 3.2 Create a simple wiring test with RSpec for the environment
- 4 Hello NGINX
- 4.2 Giving it a spin
- 5 Finding the authentication token in the request
- 6.1 Querying Redis
- 7 Handling the scenarios
- 8 Adding configuration directives
- 9 Updating the test suite
- 10 Adding a backing application
- 11 Closing thoughts
##1 Introduction
This NGINX tutorial and the accompanying video will be a look into developing modules for the NGINX web server. Typically we use web servers like NGINX and Apache as simple reverse proxies for our web based software, leaving a lot of functionality on the table. We will explore not only how to build an NGINX module, but also build something that could provide value to a web application by allowing NGINX to handle some of the early routing process.
##2 Setting up the environment
NGINX modules can be written in a number of languages. The most common are C, Perl, and Lua. This tutorial will use C as the implementation language and Ruby as a supporting language. It offers the greatest amount of control and integration with NGINX and can make a big difference in the performance department. Writing NGINX modules in C also helps you internalize the NGINX life-cycle and how it operates on requests.
###2.1 Getting started with the NGINX tutorial
Before we start there are a few things we will need in order to compile our module. Since we typically deploy to Linux this tutorial will work directly in a Linux environment. If you don't have one setup, everything here should work on OS X but the dependency install process will be a little bit different.
First, you will need a C compiler and other C based build tools. The following packages will satisfy all dependencies for this NGINX tutorial:
Along with these dependecies you will need Ruby, Rubygems, and Bundler. Ruby installers such as RVM or rbenv provide everything in one place.
###2.2 Bootstrapping a local development environment
In order to work effectively, we first need to setup a proper development environment. Since NGINX doesn't have a shared module system, it will have to be recompiled every time we want to try the module out. This can be cumbersome if we install NGINX to it's normal location. This requires root privileges when editing configuration files and starting/stopping the server. You might also have another web server running on your machine, which could create a conflict for standard tcp ports. We also need a minimal configuration so we can focus on our module. The following nginx.conf is the bare minimum configuration:
script/bootstrap
This configuration will run NGINX on port 8888 . Now that we have a configuration, we need to download and install nginx. Since we can control where nginx gets installed, we will set everything up in the same folder that we write our module code. Rather than go into a lot of detail about how to do this, the following script can be used to download and install NGINX to the proper location:
Along with installing NGINX, this script will create a symlink on the nginx.conf file that was just created. Make sure to make it executable and give it a whirl.
###2.3 Ensure the local environment is working properly
Now we are ready to test everything out and make sure it is working properly. Try the following to ensure everything worked. If you see the following then you are successfully setup and ready to go!
##3 Establishing a test harness
As we develop our module we will want to make sure that the results are as expected. Let's setup a build and test harness to help keep us in line as we write our code.
###3.1 Creating the build system
There are a lot of potential options for controlling the build and test environment. At the end of the day the best option is the one that works for you. For this exercise we will be using the Ruby language and the RSpec test framework. We will use bundler to deal with dependencies and Rake to drive compilation and test runs. We will use the curb gem to perform the calls to our web server and the redis gem to communicate with Redis. It all starts with a Gemfile:
To fetch these dependencies we need to run bundler:
Now that we have our dependencies installed let's move on to our Rakefile .
This will allow us to drive everything via Rake tasks. To ensure everything was wired up correctly you can run rake -T . You should see the following output:
You might have noticed that we are missing the file referenced in the compile task. Let's sort that out now:
script/compile
This is similar to the bootstrap compilation routine, but it adds debug flags and disables optimizations to make troubleshooting easier. Don't forget to make it executable. Let's give the compile task a try. We will use this going forward so it's a good idea to make sure it is working properly.
###3.2 Create a simple wiring test with RSpec for the environment
With dependencies and a Rakefile in place, the last thing to do before we get started on our module is write the base for our test harness. The first test we write will just ensure that the web server is running and returns an HTTP 200 OK response. First we will create our spec helper file which will be included in all of our tests:
_spec/spec helper.rb
There isn't a lot here and that's ok. It just requires the dependencies for our spec files. As you progress down the road this can offer a lot more. Next we will create our actual spec file:
_spec/integration/integration spec.rb
You can run your test using the rake command:
This shows that our test passed, but doesn't quite give us the information we want. We can change this by adding a .rspec file to our project:
Running the test now gives us a more human readable output:
Now it's time to write our module.
##4 Hello NGINX
NGINX modules consist of two parts; a config file and a module file. The config file tells NGINX how to compile the module and what it is called. The module file contains the actual code. The module file can of course be broken up into multiple files, but we will only have one for this exercise.
Let's start with the config file:
This file tells the NGINX compilation process what the module name is and where the source code can be found. We will come back to this file later to add some additional items but for now this is all we need.
##4.1 Module code
Now it's time for our actual module code.
_ngx_http_auth_token module.c
There are a few things we need to include to write our module. The four included files come from NGINX and will eventually all be necessary to complete our module. ngx_http_auth_token_module is declared as our module.
ngx_http_auth_token_handler is the function that runs when the request is processed. We will see below how it is wired into the request life-cycle, but it is the function responsible for coordinating all of the actions in this module. The function accepts the parsed request and operates on it.
First, we check to see if this function has already been invoked. NGINX has multiple phases and can sometimes invoke a handler more than once. If we see that the internal flag has been set we stop the handler from continuing by returning NGX_DECLINED . This seems counter intuitive, but that response tells NGINX to keep going. If the internal flag has not been set, the next operation sets it to mark that processing has already occurred.
The meat of this function creates a new entry for the response headers. Once the new header has been added, the function returns NGX_DECLINED to let NGINX know to continue to the next phase of processing.
The init function is responsible for wiring the handler function tovthe proper phase in the NGINX life-cycle. It gets the core nginxvconfiguration struct and creates an entry in the NGX_HTTP_ACCESS_PHASE . Finally it sets the function in the handler to the ngx_http_auth_token_handler function.
Last, we need to configure the module itself. The final two values specify how the module should be invoked. Right now most of these options are not used because our module is pretty light. Once we add configuration directives and additional code we will add on these. Running through these options we see the ngx_http_auth_token_init function referenced for the postconfiguration section. This tells NGINX to call this function when loading the module. The module declaration itself comes next. Again, we don't do much here. We use the boilerplate values and pass our ngx_http_auth_token_module_ctx as the module context argument.
###4.2 Giving it a spin
You will notice if you run rake nginx:compile that it does not compile our new module. This is because we have not included it in our compile script. Let's update that now:
This tells the NGINX compilation process to look for a module in the ../../ directory. This is accurate since the NGINX compilation process is running in the vendor/nginx-1.4.7 directory. After the compilation succeeds, give it a try:
Notice the new header X-NGINX-Tutorial: Hello World! is now in the response. We don't actually want to keep this in the response going forward, but this is an easy way to demonstrate that our code is included and running properly.
##5 Finding the authentication token in the request
Now that we have a working module it's time to write the real part of our module. The first part of which is finding the value of a cookie. In particular, we want to find the value of the cookie that contains an authentication token. To do this we will leverage a built in NGINX function called ngx_http_parse_multi_header_lines . The code is as follows:
This function takes the cookies from the request, the name of the cookie to extract, and a variable to store the value of the cookie. Right now the name of the cookie is hard coded. We will fix that when we add configuration directives. Let's update our handler to extract the value and redirect if the cookie is not found.
After adding the cookie extraction code, we added an if statement to either display the header back to the user or redirect if the header isn't present. We will continue by adding some lookup code to validate that the auth token is in fact legitimate. Let's recompile and give it a try.
##6 Looking up the authentication token in Redis
The next step is to lookup the auth token provided and ensure that it is valid. For this exercise, valid simply means that the token can be found. We will use Redis as our token storage system. There are plenty of other options, and some that work better in this scenario. Redis has a clean and easy to use C library, and makes for a lot less code. It is perfectly acceptable to use Redis in this situation.
###6.1 Querying Redis
The first thing we need is a connection to Redis. This can be achieved via the redisConnect or redisConnectWithTimeout functions. Normally, we would want to use the timeout feature to ensure that the request can fail quickly if there is a problem downstream with Redis or the network. For this example we will use redisConnect .
This populates a context struct with the Redis connection. We will pass this along when we make queries. Let's write the function we will use in our module to retrieve the user id using the auth token value. Before we write our funciton we need to include a couple more files at the top of our module.
Now we can write our lookup function:
This function accepts the auth token value from the request and a variable to hold the user id if it is found. A connection is made to redis and passed in to the redisCommand function along with the query GET <auth_token> . If the query succeeds, a string will be returned. If it fails, the reply object will have a reply type of REDIS_REPLY_NIL . We can use that to signal that the lookup failed. If so, we return NGX_DECLINED . This lets the caller know that the value didn't exist. If the lookup succeeded we need to populate the user_id variable. In NGINX, strings are a little different. A ngx_str_t consists of data and a length. They aren't null terminated. When writing NGINX modules it is best to work with their data structures. To make things easier, all functions in your module should speak NGINX types and do any necessary conversions inside. We set the data member of user_id to the reply value from Redis and cast it to a u_char * . We then set the len member to the length of the reply string and return NGX_OK .
We now have a function capable of performing our lookup. There is one more thing we need to do to have our module compile properly. We need to update our config and tell it that we want to link against the hiredis library. Here's what it should look like when we are finished:
Here we updated CORE_LIBS to include -lhireds . This will ensure that the compilation process will link against the hiredis library and our compile will succeed. Even though we haven't hooked up our new function, it's a good idea to test the compilation process now to make sure everything works properly. If you get errors, make sure the hiredis library is installed and that pkg-config is aware of it.
##7 Handling the scenarios
We are now able to retrieve the value of a cookie and look it up in Redis. The last thing our module needs is some logic. We want to redirect if the request doesn't contain the auth token, or if the auth token isn't found. If it is found, we want to allow the request to continue. In order to do this effectively, we are going to want to do a little refactoring. Let's start by extracting the two paths of our handler into functions.
First, we create a redirect function. We will be using it twice, so it's nice to have it tucked away for reuse. This is just a function extraction, nothing changed from the original code. Next, let's extract the code that's left:
Here's where things change a bit. This function takes the user id that we looked up from Redis and appends it as the value in our new header. Notice that the name of the header has changed from X-Auth-Token to X-User-Id . This is because the value we will eventually pass to our downstream application is the user id. Now we can rewrite our handler to use these new functions and put in place the logic we want.
The consequence of the cookie lookup now just invokes our redirect function. The alternative attempts to lookup the auth token using the lookup_user function. If it fails the redirect function is invoked. If it passes we invoke our append_user_id function and exit our handler. Let's recompile and test out our module.
We can see that we are being redirected in both situations where we expect. Let's add the test key into Redis and see what happens.
This time the lookup was successful and the X-User-Id header was set to the value of the test key.
This is the last time we are going to see the new header reflected back to us. It isn't useful or necessary to add it to the response. We need to make sure that the application that comes after our NGINX server sees this header. Let's modify our append_user_id function to make this happen.
If we recompile and test again, we will see that the header is no longer in the response. To test this now we will need to add a backing application. We won't do that quite yet though, there's still some finishing touches we need to put on our module.
##8 Adding configuration directives
Until now all of the values in our module were hardcoded. This doesn't make a great module. There are a few things we would like to configure:
- The Redis host
- The Redis port
- The cookie name for the auth token
- The location of the redirect
To get the idea of how we want the end result to look, let's update our nginx.conf file to reflect the desired state.
This example shows what our configuration will look like when we are finished. In NGINX there are multiple places that you can have configuration variables. The section in the http block is referred to as the NGX_HTTP_MAIN_CONF , the server block NGX_HTTP_SRV_CONF , and the location block NGX_HTTP_LOC_CONF . There are additional options that won't be discussed in this NGINX tutorial. For a full list you can visit http://lxr.nginx.org/source/src/http/ngx_http_config.h . Directives are allowed to be declared in any combination of locations. To make things a little clearer we will only use NGX_HTTP_MAIN_CONF in this example. One might argue that it would make more sense to have them in other places. While that is correct this is an exercise left to the reader.
To get started we need to create a place to hold the configuration. We will declare a struct at the top of our module.
Next, we need to add the definition for our directives.
This section of code is pretty straight forward. For each directive you have a name, the configuration location, the number of arguments it accepts, the type of argument, the configuration offset, and the value in the configuration struct to populate. There are just two more things left to do and we are ready to test it out.
Next, we need to tell the NGINX how to find these commands and what to default them to. First lets wire them in:
Note that the module directives has changed from NULL to the command list we just created. Along with this we added a reference to a function named ngx_http_auth_token_create_main_conf . This function will allocate and set default values for our configuration struct. Let's write that now.
This code allocates the auth_token_main_conf_t value to ensure that it is usable by the module. Now we need to update our code to use the configuration values. Let's update our handler.
We have now removed the hardcoded values. In their place we created an instance of our auth_token_main_conf_t and populated it using the ngx_http_get_module_main_conf function. After this we are able to use the conf variable to get to our configuration values. There is one more change that we still have to make. We added an extra argument to the lookup_user function. This is the configuration information so that the function can connect to Redis using the configuration values rather than the hardcoded ones. Let's update the function to reflect the new signature and remove the hardcoded data.
These changes are pretty straight forward. We add conf to the function signature and use its values inside the function. Remember that the conf contains NGINX data structures, so to get string values you need to use the data member of the value. Now we're ready to give it a try!
##9 Updating the test suite
Instead of firing everything up and running a bunch of curl commands, let's update our test suite to do this automatically.
_spec/integration/spec helper.rb
Before each test we reset our Redis database. This will make sure we only have the values we want inside of each of the tests. We then create three tests that express the boundaries of our module. We check the HTTP status code of the response to ensure that the module is acting the way we intend it to. Let's recompile and run our tests.
Now that we have a working test suite we have a nice base for future additions to our module.
##10 Adding a backing application
In order to see the results of our module in action we need to have an application running behind our NGINX server. It doesn't need to be fancy. In fact, it really doesn't need to do much of anything except print the user id so that we can see everything working as expected. We already have an environment setup for Ruby, so let's create a simple Ruby web application that does just this.
This program will respond if the proper auth token is presented to NGINX. Before we can test everything we need to update our NGINX configuration to add our new program as the receiver of our requests.
We added an upstream block that points to our local host at port 4567, which is where our program will run by default. Now we just need to start NGINX and our new program:
Let's make sure we have a token in our Redis database then query the server.
We can see that our module is correctly passing the information back to the downstream application.
##11 Closing thoughts
We now have a fully functioning NGINX module complete with test suite. We accomplished a lot and hopefully learned some new things. There are lots of places we can go with this module but there are a few things we should discuss before wrapping up.
- Should I use this module in production? Probably not. It is lacking some flexibility in configuration and general robustness and error handling. Along with that this module is still pretty plain. Additional features may be necessary to not take away from the intended security mechanisms that may already be in place for your application. That being said, this is a solid foundation and the rest of the work doesn't take too much additional effort.
- Where do I go from here? There are quite a few resources available. The general go to place for information is the mailing lists . There is also the canonical guide to NGINX module writing from Evan Miller. It's a great resource for general information about getting started writing modules. Finally, you should experiment with this module and see what else you can add to it and share what you have created with the world!
